Item # |
Part # |
Description |
|
1 |
N/A |
Riser Cylinder #1 |
|
2 |
N/A |
Riser Cylinder #2 |
|
3 |
N/A |
Riser Cylinder #3 |
|
4 |
N/A |
Riser Cylinder #4 |
|
5 |
N/A |
Riser Cylinder #5 |
|
6 |
N/A |
Riser Cylinder #6 |
|
7 |
N/A |
Right Hand Rajay Wastegate |
|
8 |
N/A |
Left Hand Rajay Wastegate |
|
9 |
N/A |
Right Hand Tailpipe |
|
10 |
N/A |
Left Hand Tailpipe |
|
11 |
N/A |
Left Hand Balance Tube |
|
12 |
N/A |
Right Hand Balance Tube |
|
13 |
N/A |
Adapter Turbine Inlet |
|
14* |
RJ4120-11 |
Wastegate Return Spring |
|
15* |
RJ0115 |
Turbine Inlet Gasket |
|
16* |
RJ0114 |
Turbine Outlet Gasket |
|
17* |
RJ0193 |
V-Band Coupling (Recommended Torque 45-50 Inch Pounds) |
|
18* |
3-Hole Lycoming 15486 |
Exhaust Gasket |
* Items Not Shown
